60
Rear brake wear indication
3
2
3
4
(1) Arrow (2) Brake arm
(3) Reference mark (4) Brake panel
1
(f) Brake wear indicators
When the brake is applied, an arrow (1), fixed
to the brake arm (2), moves towards a
reference mark (3) on the brake panel (4).
Front brake wear indication
( )Drum variant
(3) Adjusting nut (4) Brake joint pin
3
A
B
(A) Decrease free play (CW)
(B) Increase free play (ACW)
(3) Adjusting nut (4) Brake joint pin
ü
X
(A) Cut-out not seated (B) Cut-out seated
3
44
3
NOTE
If proper adjustment cannot be obtained by
this method, visit your Authorised Hero
MotoCorp workshop.
If the arrow aligns with the reference mark on
full application of the brake, the brake shoes
must be replaced.
1
(1) Arrow (2) Brake arm
(3) Reference mark (4) Brake panel
4
2
4
