3. Lower level mark
1. Oil level dipstick 2. Upper level mark
2
UPPER
LOWER
31
The oil level dipstick (1) is on the right
crankcase cover for measuring oil level. Oil
level must be maintained between the upper
(2) and lower (3) level marks on the oil level
dipstick.
•
Savita Oil Technologies Limited.
Do top up if oil level reaches towards the lower
level mark or every 3000 km whichever is
earlier.
OIL CAPACITY: 1 litres
•
Bharat Petroleum Corporation Limited.
Check engine oil level each day before
operating the vehicle.
Engine oil level inspection/Top up
process
•
Turn the i3s switch to “OFF” position.
•
Park the vehicle on its main stand.
•
Start the engine & let it idle for 3-5
minutes.
•
Reinstall the oil level dipstick and check for
oil leaks.
•
Quantity of oil to be filled is 0.85 litre
(approx.) during oil change when right
crankcase cover is not removed.
•
Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
•
Remove the oil level dipstick and check the
oil level.
•
top the engine and wait for 2-3 minutes.S
•
If required, add the specified oil up to the
upper level mark. Do not overfill.
The engine will stall if the i3s switch is in
“ON” position during warmup.
NOTE
Drain engine oil with the engine warm and the
vehicle on its main stand.
•
After the oil has completely drained,
reinstall the drain bolt with a new sealing
washer.
•
Reinstall the oil level dipstick with a new
O-ring.
•
Fill the crankcase through the oil filler hole
with (approximately) of the 0.85 litre
recommended grade oil.
Oil circulation inspection
•
Start the engine and allow it to idle for few
minutes.
•
To drain the oil, remove the oil level dipstick
and drain bolt (1) with sealing washer (2).
Engine oil replacement process/
3
1
