51
• Remove the fuse box (B).
• Remove the battery clamp bolt (5) and the
battery clamp (6).
8
9
6
(B) Fuse box (5) Bolt
(6) Battery clamp (7) (-)ve terminal
(8) (+)ve terminal (9) Battery
7
Fuse box : (A) Mounted on the battery
clamp (1).
Circuit fuse (2) : 15A, 10A
•
Reinstall in the reverse order of removal. Be
sure to connect the positive (+) terminal ve
first, then the negative (-) terminal.ve
Spare fuse (3) : 15A, 10A
•
Check all fasteners are secured properly.
FUSE REPLACEMENT
Battery installation
• Pullout the battery (9) from the battery box.
• Disconnect the negative (-)ve terminal lead
(7) from the battery first, then disconnect
the positive (+)ve terminal lead (8).
Fuse ype: t Blade fuse
5
Fuse ype: t Blade fuse
Spare fuse (5) : 10A
Fuse box (B) : Mounted on the battery
clamp (1).
Circuit fuse (4) : 10A
2
A
3
B
(A) &(B) Fuse box (1) Battery clamp
(2) Circuit fuse: 15A & 10A
(3) Spare fuse: 15A & 10A
(4) Circuit fuse: 10A
(5) Spare fuse: 10A
1
4
5
WARNING
!!
•
Never use a fuse with a different rating from
that specified. It may lead to serious damage
to the electrical system or a fire due to short
circuit.
•
Battery gives off explosive gases. Keep
sparks, flames & cigarettes away.
B
