14
(a) Fuel gauge
When fuel gauge needle (1) enters the red
band (2), it indicates the fuel quantity is low
and the fuel tank should be refilled as soon as
possible.
(1) Fuel gauge needle (2) Red band
2
1
Please ensure the vehicle is not used with fuel
gauge needle at red band continuously. It will
not only result in the vehicle running out of
fuel, it may also cause serious damage to the
fuel pump. Please ensure fuel is filled up as
soon as the fuel gauge needle reaches red
band.
CAUTION
!!
FEATURES
Steering lock
Steering lock with ignition switch, turn the
ignition key (1) to "OFF" ( ) position & turn
the handle bar towards left or right & push the
key downwards & turn towards "LOCK”
position. After locking take out the key.
(1) Ignition key
1. Dimmer switch
HANDLEBAR SWITCHES CONTROL
Left handlebar controls
Select “ ” for high beam and “ ” for
low beam.
1
NOTE
To check the fuel level indication, the vehicle
should be on levelled surface and in stationary
condition.
There is a clutch switch (2) provided for the
safety of the rider. The vehicle cannot be
started by electric starter switch until the clutch
lever is operated when the vehicle is engaged
in gear.
(For electric start model)
2. Clutch switch
