(2) Side stand indicator
(4) Turn signal lamp switch
(5) Clutch lever
(6) Rear view mirror
(8) Odometer
(9) Speedometer
(10) i3s indicator (optional)
(3) Horn switch
(1) Turn signal indicator
(7) Headlamp dimmer switch
(11) Neutral indicator
(21) Fuel tank cap
(12) Programmed FI malfunction indicator
lamp (MIL)
(14) High beam indicator
(13) Fuel gauge
(15) i3s switch (optional)
(16) Front brake lever
(17) Throttle grip
(18) Electric starter switch (optional)
(19) Ignition switch with steering lock
(20) Leg guard
TOP VIEW
3
5
6
15
13
17
16
21
20
18
2
VEHICLE VIEWS
4
7
1
2
8 109
11
12 14
19
*Accessories and features shown may not be part of standard fitment.
