LEFT SIDE VIEW
107
1
2
5
6
4
12
3
(7) Left side cover
(8) Saree guard with
women pillion step
(9) Rear turn signal lamp
(10) Rear reflex reflector
(5) Side stand
(3) Side stand switch
(4) Main stand
(6) Left pillion footrest
(2) Left rider footrest
(1) Gear shift pedal
(13) Throttle body/ECU
(11) Tail/stop lamp
(15) Side reflex reflector
(14) Front turn signal lamp
(12) Rear grip
3
8
9
10
11
14
15
*Accessories and features shown may not be part of standard fitment.
13
