HERO IGNITOR TECHNO - Page 7

*Accessories and features shown may not be part of standard fitment.
3
LEFT SIDE VIEW
13
12
10
1
2
3
4
5
6
7
VEHICLE VIEWS
11
8
9
(10) Tail/Stop lamp
(11) Rear grip
(13) Front turn signal lamp
(12) Side cover left
(3) Carburetor
(5) Rider foot rest
(4) Gear shift pedal
(2) Fuel valve
(1) Front reflex reflector
(6) Side stand
(7) Pillion foot rest
(8) /Seat lock Helmet
hanger
(9) Licence plate lamp
