HERO IGNITOR TECHNO - Page 8

(7) Oil level dipstick
(10) Headlamp
(6) Starter motor
(11) Front visor
(9) Front brake disc (Optional)
(8) Caliper assembly (Optional)
(12) Air suction valve
(13) Rear turn signal lamp
(14) Rear reflex reflector
(15) Exhaust muffler
(1) Pillion foot rest
(3) Kick starter pedal
(5) Brake pedal
(2) Battery compartment
(inside)
(4) Rider foot rest
13
RIGHT SIDE VIEW
*Accessories and features shown may not be part of standard fitment.
