68
(1) Bulb holder (2) Rear turn signal bulb
1
2
•
Install a new bulb in the reverse order of
removal.
•
Remove the body cover (page 35).
(f) Licence plate lamp bulb
•
Remove the screws (1) and the licence
plate lamp cover (2).
•
Remove the licence plate lamp bulb (3)
•
Install a new bulb in the reverse order of
removal.
•
Remove the rear turn signal bulb (2) by
turning it to counterclockwise direction.
(e) Rear turn signal bulb
•
Insert hand from body cover rear side, above
rear fender area and remove turn signal bulb
holder (1) by turning counter clockwise.
•
Install a new tail/stop lamp unit in the
reverse order of removal.
(1) Fuel drain tube (2) Guide (3) Screws
3 1
2
•
Remove the fuel tank lid lock cable from the
guide (2).
•
Install a new bulb in the reverse order of
removal.
•
Remove the fuel drain tube (1).
•
Remove the tail/stop lamp unit from
the body cover by removing the screws (3).
(d) Tail/Stop lamp LED unit
•
Remove the body cover (page 35).
(1) Screws (2) Licence plate lamp cover
(3) Licence plate lamp bulb
2
3
1
