23
Mount the baffleplate by inserting it diagonal into the combustion chamber.
6.7 Baffleplate
6.5 Service Interval
There is a built-in service counter set to 2.400 ON hours. This Service counter counts down from
the 2,400 ON hours. Once they have expired, an alarm will be triggered in the form of a noise and
a message in the display. This error [E002] will be visible in the display until an authorised service
technician has completed a service procedure on the stove and reset the service counter.
(The stove can still be used in this period)
6.6 Cleaning interval.
Points marked with an asterisk (*) should only be carried out by an authorised dealer.
Tools suitable for cleaning can be purchased from your authorised HETA dealer.
If the directions and cleaning schedule in this cleaning manual are not observed the warranty will
become void.
Parts / Frequency Daily Weekly Monthly Semi-/annually
Burn pot X
Ash pan X
Combustion chamber X
Glass X
Baffle plate X
Lubricate ash pan with grease X
Intake filter X
Seals and gaskets X
Pellet tank X X
Heat exchanger (*) X
Pressure switch (*) X
Convection fan (*) X
Internal flue pipe (*) X
Chimney fan (*) X
