HETRONIC Nova-M-K - Nova Transmitter Overview

11
NOVA TRANSMITTER
The Nova transmitter is a "belly box" design. The
operator uses joysticks or paddle levers to control
crane/machine motions. Standard Nova joysticks and
paddle levers have proportional speed control without
detents. Optional joysticks provide up to four speeds
with detents. The Nova joystick model can combine up
to four dual axis joysticks for up to four motion control.
The Nova paddle lever model can accommodate up to
eight single axis paddle levers for up to eight motion
control.
The Nova also offers a Selector toggle switch to control
up to seven crane/machine motions for
independent/combined control.
Nova-M transmitter components are shown below.
Nova-L transmitter components are shown below.
1 + 2
12
O
I
2
1
6
7
8
11
4
5
3
9
10
1. E-Stop Pushbutton
2. Power LED
3. Selector Toggle
Switch
4. Key Switch
5. Key Cap
6. Option Switch
7. Start/Horn
Pushbutton
8. Upper Housing
9. Carrying Belt
Retainer
10. Lower Housing
11. Joystick
Nova-M
O
I
L Trolley R
Rev Bridge For
Up Hoist Down
Option
E
M
E
R
G
E
N
C
Y
S
-
T
O
P
CCW Rotate CW
A + B
A
B
1
2
3
4
5
11
7
8
9
10
6
O
I
E
E
E
M
R
G
N
C
Y
S
T
O
P
E
E
E
M
R
G
N
C
Y
S
T
O
P
Forward
Bridge
Bridge
Reverse
Left
Trolley
Right
Down
M Hoist
Up
A Hoist
Up
A Hoist
Up
12
7
8
4
10
2
3
5
6
9
1
13
1. E-Stop Pushbutton
2. Option Toggle
Switch
3. Selector Toggle
Switch
4. Start/Horn
Pushbutton
5. Key Switch
6. Key Cap
7. Lower Housing
8. Carrying Belt
Retainer
9. Upper Housing
10. Power LED
11. Joystick
12. Paddle Lever
13. Paddle Lever Cap
Nova-L
