17
IMPORTANT: The crane/machine functions will
operate during this check. Be certain that there are no
obstacles near the crane/machine.
11. Confirm that the crane/machine moves
appropriately and that the correct LEDs illuminate
for each crane/machine motion. The LEDs are
located on the individual motion modules for
analog signals or above the discrete relays for
digital signals.
12. Activate the Option functions, if supplied, to test
optional crane/machine functions.
13. Confirm that the crane/machine moves
appropriately and that the correct LEDs illuminate
for each crane/machine motion.
14. Turn the key switch to the OFF position. All LEDs
in the receiver should turn off.
15. If transmitter and receiver function properly, the
system is ready for use.
16. If the receiver or transmitter does not operate
properly, or if the crane/machine does not react
as directed, shut the entire system down and
refer to the Troubleshooting Section of this
manual. If necessary, contact Hetronic or an
authorized service technician.
HOLDING THE TRANSMITTER
Hold the transmitter with the control panel facing you.
Be sure that you are able to easily read any text and
understand operation symbols. If your transmitter
contains a Tilt Sensor Switch, be sure it is not activated
or the transmitter will not start.
If a belt or strap is provided with your transmitter, use it
at all times. The belt or strap is designed to reduce
stress and increase safety.
The safety checks described in the following
paragraphs must be completed before the radio remote
control system is activated. These checks must be
performed at least once a day, before the start of any
operation and at all shift changes.
IMPORTANT: A transmitter drawing is included with
each system. Transmitter layout and inscriptions may
vary according to customer requests.
VISUAL CHECK
Always check the transmitter for any physical damage
before any operation.
• Always keep safety features, guards and controls
in good repair, in place and securely fastened.
• Check equipment for wear or damage.
• Check rubber cuffs and pushbutton caps for wear
or damage.
IMPORTANT: Never operate a transmitter with worn or
damaged parts. Replace immediately with only
Hetronic parts. Contact Hetronic or your Dealer.
START-UP PROCEDURE
This procedure must be carefully followed before
beginning any operation.
1. Be sure that all safety measures required by the
equipment manufacturer have been followed.
2. Be sure that the transmitter battery is fully
charged.
3. Push in the transmitter E-stop pushbutton.
4. Be sure that all controls, joysticks or paddle
levers are in the Off (neutral) position.
NOTE: If any control, joystick or paddle lever is NOT in
the Off (neutral) position when the Start/Horn button is
pushed, the transmitter will not turn on.
5. Switch the transmitter "ON". A short buzzer signal
will sound.
6. At this time, the transmitter performs a self-test
routine.
OPERATION
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal
injury and/or damage to equipment. Read and
understand the safety instructions in all
manuals provided.
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal
injury and/or damage to equipment. Always
hold the transmitter in the proper orientation.
Holding the transmitter improperly while
operating the crane/machine could result in
unexpected crane/machine response.
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal
injury and/or damage to equipment. Test the
"E-STOP" function as described in the
crane/machine manufacturer’s operator
manual before beginning any operation.
