26
GR
Weight Less than 12 lbs (incl. battery)
Size (L, W, H) 30.5 x 20.3 x 20.3 cm
12 x 8.0 x 8.0 inches
(Overall height with breastplate is
15.5")
Power supply 3.6 V 1.2 Ah NiMH rechargeable
battery
Operation time Up to 20 hours
Functions E-Stop pushbutton
7 or more motions
Horn and mainline activation
Toggle switch for auxiliary function
Selector switch (if applicable)
RECEIVER
Operating power 48/110/240 VAC 50/60 Hz (+/- 20%)
12/24 VDC (+/- 50%)
Current <100 mA
Safety features Self-monitoring E-Stop circuits
Fail-safe, spring forced E-Stop relay
Self-test during start-up and
operation
On-board diagnostic system with
indicators for RF communication,
power status, active outputs
Outputs 1 E-Stop relay
1 Horn relay
1 Start/Mainline relay
Up to 32 digital outputs
Up to 8 proportional outputs
DC applications up to 250 VDC, 5
Amp
