2.11. Offset calibration
• Offset calibration is performed in order to equalize the tolerances of the temperature
sensor and the electronics.
Perform Offset calibration
when replacing:
Where/How
− the temperature sensor
calibrate the temperature sensor.
− the CP
calibrate temperature sensor and read out the
old offset values and put them in the new CP.
− the CP-EPROM
Read out the old offset values and put them in the
new CP.
2.12. Protection
Mains power input
⇒
Mains input with overvoltage protection.
Mains switch
⇒
Thermal overload protection (fuse).
FC
⇒
Electronic protection.
Motor
⇒
Overtemperature cutout > 135°C (only 115V
version).
Cooling
⇒
Overtemperature switch in centrifuge chamber and
at condenser.
