Hi-Target iRTK5 User Manual

iRTK5 Smart GNSS System User Manual
13
2.2.2 LED
When the screen display is on:
The power LED, data LED and satellite LED will be off.
When the screen display is off:
The power LED, data LED and satellite LED will work according to the current receiver’s status.
Table 2-2-2 LED function description
Item
Status
Description
Power LED
Long-term lighting
Power sufficient
Flash
Battery low
Data LED
Flash
1. RTK mode: flash at the differential data interval.
2. Static mode
Sampling interval >1S: flash at the sampling interval;
Sampling interval ≤1S: flash once per second.
Off
1. RTK mode: no differential data.
2. Static mode: sampling has not started.
Satellite LED
Long-term lighting
Satellite tracked
Flash
Satellite not tracked
2.3 Touch screen display
The receiver has a 1.3-inch 240*240 high-resolution touch screen to support touch operation. Double-
click the power button to turn off the LCD display, and double-click the power button again, or click the
screen, to resume the LCD display.
2.3.1 Status interface
The receiver will display the current working status when it’s powered on. The status interface consists
of icons and text.
