Hi-Target iRTK5 User Manual

iRTK5 Smart GNSS System User Manual
14
Table 2-3-1 Status interface function description
Status
Icons
Text description
Internal UHF base
Displays in a cycle with the current channel,
differential data format and current power.
Internal GSM base
Unconnected to network:
Shows the status of the network.
Connected to network:
Displays in a cycle with the differential data format
and current power.
External radio base
Displays in a cycle with the differential data format
and current power.
Internal UHF rover
Shows the solution status.
Internal GSM rover
Unconnected to network:
Shows the status of the network.
Connected to network:
Shows the solution status.
External radio rover
Shows the solution status.
Data collector internet rover
Shows the solution status.
