46
6 - 6 After operation the crane (for driving)
z Retract the booms fully
z Rotate the boom at the driving position
(front or rear side. Refer the sticker on slewing cover and
column base plate)
z Retract the outrigger legs fully
z Retract the outrigger beam fully
z Lower the boom at lowest position
z Settle the hook with the safety rope on the chassis
z Operate (wind) the winch until the safe rope is tensioned
z Put manual accel lever put at neutral position
z Disengage the PTO, then the pump stop to run
(note) Driving with the pump running may
cause PTO and pump damages.
It’s very dangerous to drive without
the hook in a fixed position
Check again that the outrigger system is
fully retracted and locked.
