1) Base
The base is connected with
the column structure by slewing bearing,
which makes the crane rotate, and is
mounted on the chassis frame with
strong anchor bolts.
2) Column
The column is of a closed welded box design and connected with
the base. The column supports the boom system via derrick
cylinder.
The winch system is mounted in the column structure.
