HID DTC4000 User Manual

DTC1000/1000M/4000/4500 Ethernet User Guide – Installation Guide L001411
(Rev.1.1)
24
4
Enter the optional network settings for Ethernet communications across a
router from other subnets. The option setting is Default Gateway.
5
Enter the optional network settings for DNS. These are the following:
 DNS Server Address
 DNS Domain Suffix
6
Select the Submit button to save these changes to stored settings in the
memory of the Printer. (Note: These settings will not be lost if the power is
removed from the Printer.)
7
Log in as a root User if you are so prompted. (Note: Any change of setting
will only be accepted after you have successfully logged in.)
8
Reboot the Printer for this change to take effect
Entering the TCP Window Size
Step
Procedure
1
Select the Network link from any web page of the Printer.
2
Select the TCP window size from the drop-down menu, as shown below.
 This entry provides for entry of the TCP Window Size. It adjusts how
much data can be sent to the Printer at any one time.
 It is recommended that the default value of 2 MSS Packets be used to
ensure good compatibility with all client applications.
3
Click on the Submit button to save this setting.
4
Login as a root User if you are so prompted. (Note: Any change of a setting
will only be accepted after you have successfully logged in.)
5
Reboot the Printer to effect this change.

HID DTC4000 Specifications

General

Print Resolution	300 dpi
Memory	32 MB RAM
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capability	Single-sided
Card Capacity	100 cards
Card Sizes Accepted	CR-80
Card Thickness Accepted	0.229mm - 1.016mm
Connectivity	USB 2.0
Operating System Support	Windows 7, 8, 10
Maximum Print Width	85.6 mm
Media Handling	Automatic card feed
Media Width	54 mm
Media Thickness	0.18 - 0.36 mm
Operating Temperature	15° to 35° C
Storage Temperature	5° to 55° C
