HID PIVCLASS M2000 - Section 2: Specifications; Technical Specifications; Cable Specifications

Section 2
January 2019 7
2 Specifications
2.1 Technical specifications
2.2 Cable specifications
1
Minimum wire gauge depends on cable length and current requirements.
Parameter Specification
Dimensions
6.70 x 6.05 in (17 x 15.4 cm)
7.32 x 6.61 in (18.6 x 16.8 cm), including Enclosure
Power
Input: 12 V DC @ 1.2Amp, 24 V DC @ 600mA
(Note: PAM has a <10ms in-rush of ~2.2A on power on)
Output Reader Power: 11.5 V DC, 300 mA (each)
Relays (if equipped)
Dry Contacts
Coil: 5 V DC, 360mW
Contacts: 28 V DC, 5 Amp (resistive loads only)
Environmental
32° to 120°F (0° to 49°C)
0 to 85% RHNC, Indoor Only
Communication
Host: 10/100 Ethernet TCP/IP TLS (AES Encryption)
Smart Card Readers: Two (2) RS-485 FDX Serial Ports
Access Control System Reader Interface Module: Two (2) Wiegand Ports
Option Length Specification
Input Circuits
1
500 feet (152 m)
2-conductor, shielded, using Alpha 1292C (22 AWG) or Alpha 2421C
(18 AWG), or equivalent
Output Circuits
1
500 feet (152 m)
2-conductor, using Alpha 1172C (22 AWG) or Alpha 1897C (18 AWG),
or equivalent
Wiegand 500 feet (152 m)
Alpha 1295C, 22 AWG, 5-conductor, stranded, overall shield
Ethernet 300 feet (91 m)
Cat5, Cat5E, and Cat6
RS-485 500 feet (152 m)
Belden 3108A or equivalent, 22 AWG, 6-conductor, stranded overall
shield
