Handheld Thermal Monocular Camera User Manual
17
Chapter 6 Aiming Point Settings
6.1 Correct Reticle
Enable the reticle to view the position of the target. The functions such as freeze and zoom help to
adjust the reticle more accurately.
Steps
1. In the view mode, hold the wheel to show the menu.
2. Select . A reticle shows in the center of the view.
3. Rotate the wheel to select Reticle, and press the wheel to select a reticle No. you want to
correct.
4. Rotate the wheel to select Distance. Rotate the wheel to set the distance to the target.
5. Rotate the wheel to select Type, and press the wheel to switch the reticle type.
6. (Optional) Rotate the wheel to select Freeze, and press the wheel to enable or disable this
function.
Note
When enabling the freeze function in reticle, you can adjust the position of the cursor on a frozen
image. This function can prevent image flutter.
7. (Optional) Rotate the wheel to select Zoom, and press the wheel to switch the zoom ratio.
8. Rotate the wheel to select the coordinates, and press the wheel to switch the X and Y axis. If
you select X, the reticle moves left and right; if you select Y, the reticle moves up and down.
9. Rotate the wheel to move the reticle until it reaches the target position. The coordinates show
the current position of the reticle, and the small reticle indicates the initial position of the
reticle.
