HIKVISION DS-1600KI User Manual

23
Configure Date & Time:
Steps:
1. Click the Date & Time button on the right of the General interface to enter the configuration interface.
Figure 3.11 Date and Time Configuration Interface
2. Set the date and time in two ways.
Task 1: Automatic mode
Steps:
Enable the automatic mode by switching to , or else the manual mode is enabled.
Task 2: Manual mode
Steps:
1) Click to set the current date as shown in Figure 3.12.
2) Click to set the current time as shown in Figure 3.12.
Figure 3.12 Date and Time Configuration
Select Time Zone:
Steps:
Click to select time zone in your location. The pop-up interface is shown in Figure 3.13.

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
