1.1 Introduction
DS-1600KI is the new generation of fully touch-enabled and detachable network keyboard independently
developed by Hikvision. In addition to displaying images, the 10.1" capacitive touchscreen supports DVI and
HDMI video outputs. It runs on Android 4.4 and has the brand new UI design. It is compatible with all series of
front-end and back-end devices of Hikvision and control center platform such as iVMS. It supports recording,
picture capturing and two-way audio, as well as the video wall control and scene switch of iVMS and decoding
devices. The four-axis joystick can be used to the PTZ control of speed dome and quick location of the target. The
joystick panel is detachable for the convenience of operation. This keyboard can be widely used in various video
surveillance fields.
1.2 Appearance
Figure 1.1 Appearance of DS-1600KI Keyboard
The DS-1600KI keyboard consists of a touchscreen and a joystick panel. The joystick panel is detachable and can
be separated from the keyboard. Refer to Table 1.1 for the description of the keyboard appearance.
Table 1. 1 Description of Keyboard Appearance
10.1" capacitive touchscreen for display, configuration and operation of the
keyboard.
Used for picture capture.
Refer to Table 1.2 for the description of the joystick operations.
Table 1. 2 Description of Joystick Operations
PTZ control mode: Move the PTZ up.
PTZ control mode: Move the PTZ down.
