HIKVISION DS-1600KI - Managing the Groups

39
 When editing Name and Channel ID, you can click to delete the original information.
 The range of the Channel ID is from 1 to 999999, and the ID cannot be repeated.
2. Click to select the protocol.
Figure 4.22 Selecting the Protocol
3. Click to select the stream.
Figure 4.23 Selecting the Stream Type
4. Click to confirm the modification.
5. (Optional) You can click to cancel the modification.
4.2.3 Managing the Groups
For the admin and operators, the group management steps are the same. This section takes the operations
of the admin as an example.
Purpose:
You can add the relevant cameras into the same group to make them easy to manage. E.g., you can add all the
cameras of the underground garage into one group.
You can add/delete/modify groups in the Group Management interface. And some other basic operations are
supported, including viewing the group details, and clearing all the groups.
Select Group on the right side to enter the Group Management interface.
