HIKVISION DS-1600KI User Manual

50
then select multi-window division mode.
Figure 4.42 Hint box of Starting Auto-Switch of the Group (1)
Figure 4.43 Hint box of Starting Auto-Switch of the Group (2)
4. Enter 0 in the numeric panel and click . You can stop the live view of the corresponding camera.
5. (Optional) You can click to delete the entered information if you entered incorrectly.
6. (Optional) You can click or to preview the previous or next camera or group.
7. (Optional) You can double-click the selected window to realize full-screen live view. Or double-click in the
full-screen mode to restore to the normal live view mode.
8. (Optional) You can click to stop the local live view.
PTZ Control
In the live view mode, select a playing window and click to activate PTZ control panel, and the
changes to .
Figure 4.44 PTZ Control Panel

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
