HIKVISION DS-1600KI User Manual

75
Figure 5.3 Resource List of Video Wall
The number on the upper-right corner of each item stands for the serial number of the video wall. Click a video
wall to enter the Scene List interface.
Figure 5.4 Scene List
Steps:
1. Call the scene by clicking .
2. Click to exit from the Scene List interface and return to the Resource List interface.
After calling the scene of the video wall, appears on the right-bottom corner of the selected video
wall item, indicating that the video wall is in use.
3. Log in to the iVMS platform, and click Logical View->Camera to enter the following interface.
Figure 5.5 Camera List

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
