HIKVISION DS-2CD6362F-I User Manual

User Manual of Network Fisheye Camera
54
editing interface of the arming schedule.
(2)Choose the day you want to set the arming schedule.
(3)Click to set the time period for the arming schedule.
(4)After you set the arming schedule, you can copy the schedule to other days
(Optional).
(5)Click to save the settings.
Note: The time of each period can’t be overlapped. Up to 4 periods can be
configured for each day.
Figure 5-33 Arming Time Schedule
3. Set the Alarm Actions for Motion Detection.
Purpose:
You can specify the linkage method when an event occurs. The following
contents are about how to configure the different types of linkage method.
Figure 5-34 Linkage Method

HIKVISION DS-2CD6362F-I Specifications

General

Type	IP security camera
PTZ control	Yes
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Total megapixels	6 MP
Maximum resolution	3072 x 2048 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1024 x 768 (XGA), 2048 x 1536 (QXGA)
Camera shutter speed	1/25 - 1/100000 s
Minimum illumination	0.3 lx
Field of view (FOV) angle	360 °
Sensor type	CMOS
Optical sensor size	1/1.8 \
Optical zoom	- x
Focus adjustment	2.8
Fixed focal length	- mm
Password protection type	User
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	64 GB
LED type	IR
Night vision distance	15 m
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTC P, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Ethernet LAN (RJ-45) ports	1
Signal-to-Noise Ratio (SNR)	120 dB
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	11 W
Operating temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	152.8 mm
Width	164 mm
Height	43.8 mm
Weight	1400 g
