HIKVISION DS-2CD754FWD-E Installation Manual

Installation Manual of Network Camera
36
Figure 3-43 Drill Template
2. Secure the back box to the wall with screws.
Note: Position the side cable outlet directly below to prevent moisture from getting inside the
camera.
Figure 3-44 Secure the Back Box
3. Loosen the set screws with the hex key (supplied) to remove the lower dome; remove the dome
liner.
Cable hole
