Page #114 background imageLoading...
Page #114 background image
© Hikvision
Configuring Text Overlay Settings
Purpose:
You can customize the text overlay.
Steps:
1. Enter the Text Overlay settings interface:
Configuration > Image > OSD Settings
2. Check the checkbox in front of textbox to enable the on-screen display.
3. Input the characters in the textbox.
4. Use the mouse to drag the red text frame Text in the live view window to adjust the text
overlay position.
5. Click to save the settings.
6.3.3 Configuring Image Parameters Switch
Purpose:
You can configure Link to Preset or Scheduled-Switch in order to switch to linked scene in certain
time.
Link to Preset: Set the time period and linked scene for the preset and check the
corresponding checkbox to go to the linked scene in the configured time period.
Scheduled-Switch: Set the time period and linked scene and it will go to the linked scene in
the configured time period when you check the corresponding checkbox.
Note:
This function varies depending on different camera models
Steps:
1. Enter the Image Parameters Switch interface:
Configuration > Image > Image Parameters Switch
2. Check the checkbox of Link to Preset or Scheduled-Switch to enable the function. (Only one
function can be enabled in the same time.)
3. When you enable the function of Link to Preset, select one preset from the dropdown list,
check the corresponding checkbox, set the time period and the linked scene for the selected
preset. (Up to 4 periods can be configured for one preset.)
Figure 6-39 Link to Preset

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DE4225W-DE and is the answer not in the manual?

HIKVISION DS-2DE4225W-DE Specifications

General IconGeneral
Sensor typeCMOS
Progressive scanYes
Number of sensors1
Optical sensor size1/2.8 \
FocusMotorized/Manual
Digital zoom16 x
Optical zoom25 x
Focal length range- mm
Maximum aperture number3.5
Minimum aperture number1.6
Closest focusing distance0.01 m
Pan range0 - 360 °
Pan speed160 °/sec
White balanceATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range0 - 90 °
Camera shutter speed1/1 - 1/30000 s
Minimum illumination0.001 lx
Total megapixels2 MP
Gain control typeAuto/Manual
Maximum resolution1920 x 1080 pixels
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology3D noise reduction
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
TypeIP security camera
PTZ modesAuto Scan, Preset point
Languages supportBUL, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR
Number of languages32
Placement supportedOutdoor
Connectivity technologyWired
Voice codecsG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2
Audio input channels1 channels
Audio formats supportedPCM
Behavior analysisIntrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size256 GB
Number of users32 user(s)
Networking standardsIEEE 802.1x, IEEE 802.3at
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
DC output voltage12
Power source typeDC, PoE
Power consumption (max)18 W
Operating temperature (T-T)-30 - 65 °C
Operating relative humidity (H-H)0 - 90 %
Form factorDome
Mounting typeCeiling/wall
Product colorBlack, White
International Protection (IP) codeIP66
Weight and Dimensions IconWeight and Dimensions
Height239.5 mm
Weight2000 g
Diameter180 mm
