© Hikvision
Figure 6-13 Platform Access
2. Check the Enable checkbox to enable the platform access function of the device.
3. Select the Platform Access Mode.
If you select Platform Access Mode as Hik-Connect,
1) Click and read "Terms of Service" and "Privacy Policy" in pop-up window.
2) Create a verification code or change the verification code for the camera.
Notes:
The verification code is required when you add the camera to Hik-Connect app.
For more information about the Hik-Connect app, refer to Hik-Connect Mobile Client
User Manual.
4. You can use the default server address. Or you can check the Custom checkbox on the right
and input a desired server address.
5. Click to save the settings.
Note:
Hik-Connect is an application for mobile devices. With the App, you can view live image of the
camera, receive alarm notification and so on.
Configuring HTTPS Settings
Purpose:
HTTPS consists of SSL&HTTP. It is used for encryption transmission, identity authentication
network protocol which enhances the security of WEB accessing.
For your privacy and to better protect your system against security risks, we strongly
recommend the use of strong passwords for all functions and network devices. The password
should be something of your own choosing (using a minimum of 8 characters, including
upper case letters, lower case letters, numbers and special characters) in order to increase
the security of your product.
Proper configuration of all passwords and other security settings is the responsibility of the
installer and/or end-user.
Steps:
1. Enter the HTTPS settings interface.
Configuration > Network > Advanced Settings > HTTPS

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DE4225W-DE and is the answer not in the manual?

HIKVISION DS-2DE4225W-DE Specifications

General IconGeneral
Sensor typeCMOS
Progressive scanYes
Number of sensors1
Optical sensor size1/2.8 \
FocusMotorized/Manual
Digital zoom16 x
Optical zoom25 x
Focal length range- mm
Maximum aperture number3.5
Minimum aperture number1.6
Closest focusing distance0.01 m
Pan range0 - 360 °
Pan speed160 °/sec
White balanceATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range0 - 90 °
Camera shutter speed1/1 - 1/30000 s
Minimum illumination0.001 lx
Total megapixels2 MP
Gain control typeAuto/Manual
Maximum resolution1920 x 1080 pixels
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology3D noise reduction
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
TypeIP security camera
PTZ modesAuto Scan, Preset point
Languages supportBUL, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR
Number of languages32
Placement supportedOutdoor
Connectivity technologyWired
Voice codecsG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2
Audio input channels1 channels
Audio formats supportedPCM
Behavior analysisIntrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size256 GB
Number of users32 user(s)
Networking standardsIEEE 802.1x, IEEE 802.3at
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
DC output voltage12
Power source typeDC, PoE
Power consumption (max)18 W
Operating temperature (T-T)-30 - 65 °C
Operating relative humidity (H-H)0 - 90 %
Form factorDome
Mounting typeCeiling/wall
Product colorBlack, White
International Protection (IP) codeIP66
Weight and Dimensions IconWeight and Dimensions
Height239.5 mm
Weight2000 g
Diameter180 mm
