Chapter 5 System Configuration
5.1 Storage Settings
Before you start:
To configure record settings, make sure that you have the network storage device within the
network or the memory card inserted in your camera.
5.1.1 Configuring Recording Schedule
Purpose:
There are two kinds of recording for the camera: manual recording and scheduled recording. In
this section, you can follow the instructions to configure the scheduled recording. By default, the
record files of scheduled recording are stored in the memory card (if supported) or in the
network disk.
Steps:
1. Enter the Record Schedule settings interface:
Configuration > Storage > Schedule Settings > Record Schedule
Figure 5-1 Recording Schedule Interface
2. Check the checkbox to enable scheduled recording.
3. To set the advanced settings of the camera, click to enter the advanced settings
interface.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DE4225W-DE and is the answer not in the manual?

HIKVISION DS-2DE4225W-DE Specifications

General IconGeneral
Sensor typeCMOS
Progressive scanYes
Number of sensors1
Optical sensor size1/2.8 \
FocusMotorized/Manual
Digital zoom16 x
Optical zoom25 x
Focal length range- mm
Maximum aperture number3.5
Minimum aperture number1.6
Closest focusing distance0.01 m
Pan range0 - 360 °
Pan speed160 °/sec
White balanceATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range0 - 90 °
Camera shutter speed1/1 - 1/30000 s
Minimum illumination0.001 lx
Total megapixels2 MP
Gain control typeAuto/Manual
Maximum resolution1920 x 1080 pixels
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology3D noise reduction
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
TypeIP security camera
PTZ modesAuto Scan, Preset point
Languages supportBUL, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR
Number of languages32
Placement supportedOutdoor
Connectivity technologyWired
Voice codecsG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2
Audio input channels1 channels
Audio formats supportedPCM
Behavior analysisIntrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size256 GB
Number of users32 user(s)
Networking standardsIEEE 802.1x, IEEE 802.3at
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
DC output voltage12
Power source typeDC, PoE
Power consumption (max)18 W
Operating temperature (T-T)-30 - 65 °C
Operating relative humidity (H-H)0 - 90 %
Form factorDome
Mounting typeCeiling/wall
Product colorBlack, White
International Protection (IP) codeIP66
Weight and Dimensions IconWeight and Dimensions
Height239.5 mm
Weight2000 g
Diameter180 mm
