Page #19 background imageLoading...
Page #19 background image
© Hikvision
2.2.2 Dynamic IP Connection
Before you start:
Apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network
camera to a modem or a router.
Connecting the network camera via a router
Steps:
1. Connect the network camera to the router.
2. In the camera, assign a LAN IP address, the subnet mask and the gateway. Refer to Section
2.1.2 for detailed LAN configuration.
3. In the router, set the PPPoE user name, password and confirm the password.
For your privacy and to better protect your system against security risks, we strongly
recommend the use of strong passwords for all functions and network devices. The
password should be something of your own choosing (using a minimum of 8 characters,
including upper case letters, lower case letters, numbers and special characters) in order
to increase the security of your product.
Proper configuration of all passwords and other security settings is the responsibility of
the installer and/or end-user.
4. Set port mapping. e.g. 80, 8000 and 554 ports. The steps for port mapping vary depending on
different routers. Call the router manufacturer for assistance with port mapping.
5. Apply a domain name from a domain name provider.
6. Configure the DDNS settings in the setting interface of the router.
7. Visit the camera via the applied domain name.
Connecting the network camera via a modem
Purpose:
This camera supports the PPPoE auto dial-up function. The camera gets a public IP address by
ADSL dial-up after the camera is connected to a modem. You need to configure the PPPoE
parameters of the network camera. Refer to Section 6.1.1 Configuring PPPoE Settings for
detailed configuration.
Note:
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes after
rebooting the camera. To solve the inconvenience of the dynamic IP, you need to get a domain
name from the DDNS provider (e.g. DynDns.com). Follow the steps below for normal domain
name resolution and private domain name resolution to solve the problem.
Normal Domain Name Resolution
Steps:
1. Apply a domain name from a domain name provider.
2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to
Section 6.1.1 Configuring DDNS Settings for detailed configuration.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DE4225W-DE and is the answer not in the manual?

HIKVISION DS-2DE4225W-DE Specifications

General IconGeneral
Sensor typeCMOS
Progressive scanYes
Number of sensors1
Optical sensor size1/2.8 \
FocusMotorized/Manual
Digital zoom16 x
Optical zoom25 x
Focal length range- mm
Maximum aperture number3.5
Minimum aperture number1.6
Closest focusing distance0.01 m
Pan range0 - 360 °
Pan speed160 °/sec
White balanceATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range0 - 90 °
Camera shutter speed1/1 - 1/30000 s
Minimum illumination0.001 lx
Total megapixels2 MP
Gain control typeAuto/Manual
Maximum resolution1920 x 1080 pixels
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology3D noise reduction
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
TypeIP security camera
PTZ modesAuto Scan, Preset point
Languages supportBUL, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR
Number of languages32
Placement supportedOutdoor
Connectivity technologyWired
Voice codecsG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2
Audio input channels1 channels
Audio formats supportedPCM
Behavior analysisIntrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size256 GB
Number of users32 user(s)
Networking standardsIEEE 802.1x, IEEE 802.3at
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
DC output voltage12
Power source typeDC, PoE
Power consumption (max)18 W
Operating temperature (T-T)-30 - 65 °C
Operating relative humidity (H-H)0 - 90 %
Form factorDome
Mounting typeCeiling/wall
Product colorBlack, White
International Protection (IP) codeIP66
Weight and Dimensions IconWeight and Dimensions
Height239.5 mm
Weight2000 g
Diameter180 mm
