Chapter 4 Basic Operations
In this and the following chapters, operation of the speed dome by the web browser will be taken
as an example.
4.1 Power-up Action
After power up, the speed dome will perform self-test action. It begins with lens action and then
pan/tilt movement.
After the self-test action, the system information of the speed dome including model, address,
communication, version, and others will be displayed on screen for 40 seconds.
4.2 Configuring Local Parameters
The local configuration refers to the parameters of the live view and other operations using the
web browser.
Steps:
1. Enter the Local Configuration interface:
Configuration > Local
2. Configure the following settings:
Live View Parameters: Set the Protocol, Play Performance, Rules, Display POS Information
and Image Format.
Protocol: TCP, UDP, MULTICAST and HTTP are selectable.
TCP: Ensures complete delivery of streaming data and better video quality, yet the
real-time transmission will be affected.
UDP: Provides real-time audio and video streams.
MULTICAST: It’s recommended to select the protocol type to MULTICAST when using
the Multicast function.
HTTP: Allows the same quality as of TCP without setting specific ports for streaming
under some network environments.
Play Performance: Set the live view performance to Shortest Delay, Balanced, Fluent or
Custom. For Custom, you can set the frame rate for live view.
Rules: You can enable or disable the rules of dynamic analysis for motion here.
Display POS Information: Enable the function, feature information of the detected target
is dynamically displayed near the target in the live image.
Image Format: The captured pictures can be saved as different format. JPEG and BMP are
available.
