100
Please ensure that the router obtains an IP address from the public network. This function may not
work on a host with an IP address of a private network or an intranet IP address assigned by ISPs
that start with 100. Common IPv4 addresses are classified into class A, class B and class C. Private
IP addresses of class A range from 10.0.0.0 to 10.255.255.255; Private IP addresses of class B range
from 172.16.0.0-172.31.255.255; Private IP addresses of class C range from 192.168.0.0-
192.168.255.255.
Application scenario
Smart phone
FTP server
IP: 192.168.0.125
MAC: 00:00:00:00:00:01
Port number: 21
Access using a
domain name
The information of the registered DDNS
service:
− Service provider: oray.com
− User name: JohnDoe
− Password: JohnDoe123456
− Domain name: XXXX.zicp.vip

HIKVISION DS-3WR12C Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	48 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	Link
Output current	1 A
Output voltage	9 V
Power source type	DC
Cables included	LAN (RJ-45)
Antenna type	2x2
Antennas quantity	4
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Package depth	59 mm
Package width	306 mm
Package height	290 mm
Number of products included	1 pc(s)
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	213.34 mm
Width	248.4 mm
Height	154.8 mm
Weight	222 g
