HIKVISION DS-3WR12C User Manual

WiFi Router • User Guide
90
IP-MAC binding
Through the IP-MAC binding function, specified clients can always obtain the same IP address
when connecting to the router, ensuring that the router's "Port Mapping", "DDNS", "DMZ host"
and other functions can function normally. This function takes effect only when the DHCP server
function of the router is enabled.
To access the configuration page, log in to the web UI of the router, and navigate to Advanced > IP-
MAC Binding.
IP-MAC binding
IP-MAC binding parameter description
IP Address
It specifies the IP address to be reserved for the client with the specified
MAC address. It should belong to the DHCP address pool.
MAC Address
It specifies the MAC address of the client that needs a fixed IP address.
Operation
: It is used to add an IP-MAC binding rule.
: It is used to delete an IP-MAC binding rule.
Scenario: You have set up an FTP server within your LAN.
Goal: Assign a fixed IP address to the host of the FTP server and prevent the failure of access to the
FTP server owing to the change of IP address.
Solution: You can configure the IP-MAC binding function to reach the goal.
Assume that the information of the FTP server includes:
- The fixed IP address for the server: 192.168.0.136
- MAC address of the FTP server host: 00 00 00 00 00 01
Parameter
Description

HIKVISION DS-3WR12C Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	48 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	Link
Output current	1 A
Output voltage	9 V
Power source type	DC
Cables included	LAN (RJ-45)
Antenna type	2x2
Antennas quantity	4
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Package depth	59 mm
Package width	306 mm
Package height	290 mm
Number of products included	1 pc(s)
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	213.34 mm
Width	248.4 mm
Height	154.8 mm
Weight	222 g
