HIKVISION DS-3WR12C User Manual

WiFi Router • User Guide
101
Procedures:
Launch a web browser on a device connected to the router and visit
http://hikvisionwifi.local to log in to the web UI of the router.
Configure the DDNS function.
1) Navigate to Advanced > DDNS.
2) Set DDNS to Enable.
3) Select a service provider, which is oray.com in this example.
4) Enter the user name and password, which are JohnDoe and JohnDoe123456 in this
example.
5) Click Save at the bottom of the page.
Configure DDNS
Wait a moment, when the Connection Status turns Connected, the configurations succeed.
Configure the port mapping function (refer to Port mapping).
When completing the configurations, users from the internet can access the FTP server by visiting
“Intranet service application layer protocol name://the domain name”. If the external port number
is not the same as the default intranet service port number, the visiting address should be:
“Intranet service application layer protocol name://the domain name:external port number”.

HIKVISION DS-3WR12C Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	48 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	Link
Output current	1 A
Output voltage	9 V
Power source type	DC
Cables included	LAN (RJ-45)
Antenna type	2x2
Antennas quantity	4
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Package depth	59 mm
Package width	306 mm
Package height	290 mm
Number of products included	1 pc(s)
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	213.34 mm
Width	248.4 mm
Height	154.8 mm
Weight	222 g
