HIKVISION DS-3WR12C User Manual

WiFi Router • User Guide
83
Specify the period when the target websites cannot be accessed, which is 8:00 ~ 22:00 in
this example.
Tick the days when the rule is applied, which are Saturday and Sunday in this example.
Set Website Restrictions to Only Forbid.
Set Blocked Websites, which are facebook.com, twitter.com, youtube.com and
instagram.com.
Click Save at the bottom of the page.
Set parental control rules
After the configuration is completed, your daughter can access any websites except for Facebook,
Twitter, Youtube, and Instagram from 8:00 to 22:00 on weekends, and she cannot access the
internet at all between 22:00 to 8:00.

HIKVISION DS-3WR12C Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	48 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	Link
Output current	1 A
Output voltage	9 V
Power source type	DC
Cables included	LAN (RJ-45)
Antenna type	2x2
Antennas quantity	4
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Package depth	59 mm
Package width	306 mm
Package height	290 mm
Number of products included	1 pc(s)
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	213.34 mm
Width	248.4 mm
Height	154.8 mm
Weight	222 g
