HIKVISION DS-7100 User Manual

User Manual of Digital Video Recorder
102
Figure 6. 6 Video Search by Motion Detection
4. Click Search , and the record files matching the search conditions will be displayed on a list.
5. Select and click button to play back the record files.
You can click
Back to return to the search interface.
If there is only one channel triggered, clicking button takes you to Full-screen Playback interface of
this channel.
If several channels are triggered, clicking button takes you to the synch playback interface. Check
checkbox to select one channel for playback or select multiple channels for synchronous playback.
The max. number of channels for synchronous playback supported varies to different models.
Figure 6. 7 Select Channels for Synchronous Playback

HIKVISION DS-7100 Specifications

General

Video Compression	H.264
Video Input	4/8/16 channels
Audio Compression	G.711
Resolution	720P
Hard Drive	SATA
Network Interface	RJ45 10M / 100M Ethernet interface
USB Interface	2 x USB 2.0
Operating Temperature	-10 °C ~ +55 °C (14 °F ~ 131 °F)
Operating Humidity	10% ~ 90%
Audio Output	1-ch RCA(Linear, 1kΩ)
