User Manual of Digital Video Recorder
35
2.2 Setting the Admin Password
Purpose:
For the first-time access, you need to activate the device by setting an admin password. No operation is allowed
before activation. You can also activate the device via Web Browser, SADP or Client Software.
Steps:
1.
Input the same password in the text field of Create New Password and Confirm New Password.
Figure 2. 3 Settings Admin Password
2.
Click OK to save the password and activate the device.
For the old version device, if you update it to the new version, the following dialog box will pop up once the
device starts up. You can click YES and follow the wizard to set a strong password.
Figure 2. 4 Warning
STRONG PASSWORD RECOMMENDED
We highly recommend you create a strong
password of your own choosing (using a minimum of 8 characters, including upper case
letters, lower case letters, numbers, and special characters) in order to increase the security
of your product. And we recommend you reset your password regularly, especially in the high
security system, resetting the password monthly or weekly can better protect your product.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7100 and is the answer not in the manual?

HIKVISION DS-7100 Specifications

General IconGeneral
Video CompressionH.264
Video Input4/8/16 channels
Audio CompressionG.711
Resolution720P
Hard DriveSATA
Network InterfaceRJ45 10M / 100M Ethernet interface
USB Interface2 x USB 2.0
Operating Temperature-10 °C ~ +55 °C (14 °F ~ 131 °F)
Operating Humidity10% ~ 90%
Audio Output1-ch RCA(Linear, 1kΩ)
