User Manual of Digital Video Recorder
36
2.3 Using the Wizard for Basic Configuration
By default, the Setup Wizard starts once the device has loaded.
Figure 2. 5 Start Wizard Interface
Operating the Setup Wizard:
1. The Start Wizard can walk you through some important settings of the device. If you don’t want to use the
Start Wizard at that moment, click Exit. You can also choose to use the Start Wizard next time by leaving
the “Start wizard when device starts?” checkbox checked.
2. Click Next to enter the date and time settings window.
Figure 2. 6 Date and Time Settings
3. After the time settings, click Next button which will take you back to the General Network Setup Wizard
window, as shown in Figure 2. 7.

HIKVISION DS-7100 Specifications

General

Video Compression	H.264
Video Input	4/8/16 channels
Audio Compression	G.711
Resolution	720P
Hard Drive	SATA
Network Interface	RJ45 10M / 100M Ethernet interface
USB Interface	2 x USB 2.0
Operating Temperature	-10 °C ~ +55 °C (14 °F ~ 131 °F)
Operating Humidity	10% ~ 90%
Audio Output	1-ch RCA(Linear, 1kΩ)
