HIKVISION DS-7100

User Manual of Digital Video Recorder
24
1.2 IR Remote Control Operations
1
The DVR may also be controlled with the included IR remote control, shown in Figure 1. 8.
Batteries (2×AAA) must be installed before operation.
Figure 1. 8 Remote Control
The keys on the remote control resemble the ones on the front panel. Refer to Table 1. 7, they include:
Table 1. 7 Description of the IR Remote Control Buttons
No.
Name
Description
1 POWER
Power on/off the device.
Power on/off the device by pressing and holding the button
for 3 seconds.
2 MENU Button
Press the button to return to the main menu (after successful login).
Press and hold the button for 5 seconds will turn off audible key beep.
In PTZ Control mode, the MENU button will start wiper (if applicable).
In Playback mode, it is used to show/hide the control interface.
3 REC Button
Enter the Manual Record setting menu.
In PTZ control settings, press the button and then you can call a PTZ preset
by pressing Numeric button.
1
Does not apply to DS-7100, which does not support remote control use.
