HIKVISION DS-7100 User Manual

128
User Manual of Digital Video Recorder
Figure 8. 7 Set Arming Schedule of Alarm Input
5. Select Linkage Action tab to set up alarm response actions of the alarm input (please refer to Chapter 8.8
Setting Alarm Response Actions
).
Repeat the above steps to set up arming schedule of other days of a week. You can also use Copy button
to copy an arming schedule to other days.
6. If necessary, select PTZ Linking tab and set PTZ linkage of the alarm input.
Set PTZ linking parameters and click the
OK button to complete the settings of the alarm input.
Please check whether the PTZ or speed dome supports PTZ linkage.
One alarm input can trigger presets, patrol or pattern of more than one channel. But presets, patrols and
patterns are exclusive.
Figure 8. 8 Set PTZ Linking of Alarm Input
7. If you want to set handling action of another alarm input, repeat the above steps or just copy the above
settings to it.

HIKVISION DS-7100 Specifications

General

Video Compression	H.264
Video Input	4/8/16 channels
Audio Compression	G.711
Resolution	720P
Hard Drive	SATA
Network Interface	RJ45 10M / 100M Ethernet interface
USB Interface	2 x USB 2.0
Operating Temperature	-10 °C ~ +55 °C (14 °F ~ 131 °F)
Operating Humidity	10% ~ 90%
Audio Output	1-ch RCA(Linear, 1kΩ)
