User Manual of Digita
l Video Recorder
162
Figure 9. 30
Export N
etwork Packe
t
4.
Click the
Export
button to start
exporting.
5.
After the exporting is c
om
plete, click
OK
to finish the packet
export.
Up to 1M data ca
n be exported each time.
161
