HIKVISION DS-7104HWI-SL User Manual

User Manual of Digital Video Recorder
10
10.6 Configuring HDD Error Alarms ..................................................................... 131
Chapter 11Camera Settings ................................................................................................ 132
11.1 Configuring OSD Settings ............................................................................. 133
11.2 Configuring Video Parameters ....................................................................... 135
Chapter 12Device Management and Maintenance ........................................................... 136
12.1 Viewing System Information ......................................................................... 137
12.2 Searching & Exporting Log Files ................................................................... 138
12.3 Importing/Exporting Configuration Files ....................................................... 140
12.4 Upgrading System .......................................................................................... 142
12.4.1 Upgrading by Local Backup Device ...................................................... 142
12.4.2 Upgrading by FTP .................................................................................. 142
12.5 Restoring Default Settings ............................................................................. 144
Chapter 13Others ................................................................................................................. 145
13.1 Configuring General Settings ......................................................................... 146
13.2 Configuring DST Settings .............................................................................. 147
13.3 Configuring More Settings ............................................................................. 148
13.4 Managing User Accounts ............................................................................... 149
13.4.1 Adding a User ........................................................................................ 149
13.4.2 Deleting a User ....................................................................................... 151
13.4.3 Editing a User ......................................................................................... 152
13.5 Logging out/Shutting down/Rebooting Device .............................................. 154
Chapter 14Appendix ............................................................................................................ 155
Glossary ....................................................................................................................... 156
FAQ…………………………………………………………………………………….157

HIKVISION DS-7104HWI-SL Specifications

General

Product color	White
Rack capacity	1U
Maximum frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x576, 704x480
BNC input ports	8
Video input channels	4 channels
USB 2.0 ports quantity	2
VGA (D-Sub) output ports	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
DC voltage	12 V
Power consumption (typical)	6 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	200 mm
Height	45 mm
Weight	800 g
