General| Product color | White |
|---|---|
| Rack capacity | 1U |
| Maximum frame rate | 30 fps |
| Maximum video resolution | 1920 x 1080 pixels |
| Video compression formats | H.264 |
| Analog signal format system | NTSC, PAL |
| Playback resolutions supported | 1920x1080, 1280x1024, 1280x720, 1024x768, 704x576, 704x480 |
| BNC input ports | 8 |
| Video input channels | 4 channels |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) output ports | 1 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| HDD interface | Serial ATA |
| Maximum HDD capacity | 4000 GB |
| DC voltage | 12 V |
| Power consumption (typical) | 6 W |
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
Weight and Dimensions| Width | 200 mm |
|---|---|
| Height | 45 mm |
| Weight | 800 g |
