Quick Operation Guide of Network Video Recorder
19
each channel.
2
Playback
Window
Displays the image of channel.
3
Play Control
Bar
Play control operations are supported.
4
Time Line
Displays the time bar and the records marked with
different colors.
5
Playback
Status
Displays the playback status, including channel
number and playback speed.
6
Calendar
You can select the date to play.
Start Playback
Steps:
1. Click Playback on the menu bar to enter playback interface.
2. Click the camera from the device list for playback.
3. Select the date from the calendar and click Search.
4. Click the Play button to play the video file searched on the current date.
5. Use the buttons on the toolbar to operate in playback mode.
Button
Description
Button
Description
/
Play/Pause
Stop

HIKVISION DS-7108NI-E1/V/W Specifications

General

Maximum resolution	- pixels
Video input channels	8 channels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	12 W
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv6, UPnP, SNMP, NTP, SADP, DDNS, SMTP, NFS, iSCSI
HDD capacity	0 GB
HDD interface	-
Maximum storage capacity	- TB
Number of HDDs installed	0

Weight and Dimensions

Width	870 mm
Height	157 mm
Weight	530 g
