Quick Operation Guide of Network Video Recorder
32
Click the icon to enable the record, and the icon turns to . And click icon
to disable the record, then the icon turns to .
All-day Recording
Steps:
1. On the live view window, right lick the window and move the cursor to the Start
Recording option, and select Continuous Record or Motion Detection Record
on your demand.
2. And click the Yes button in the popup Attention message box to confirm the
settings.
Then all the channels will start to record in the selected mode.
Playback
Play back the record files of a specific channel in the live view menu. Channel switch is
supported.
 Option 1:
Choose a channel under live view using the mouse and click the button in the
shortcut operation menu.

HIKVISION DS-7108NI-E1/V/W Specifications

General

Maximum resolution	- pixels
Video input channels	8 channels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	12 W
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv6, UPnP, SNMP, NTP, SADP, DDNS, SMTP, NFS, iSCSI
HDD capacity	0 GB
HDD interface	-
Maximum storage capacity	- TB
Number of HDDs installed	0

Weight and Dimensions

Width	870 mm
Height	157 mm
Weight	530 g
