HIKVISION DS-7108NI-E1/V/W User Manual

Quick Operation Guide of Network Video Recorder
31
Alarm (video loss, tampering, motion detection or sensor alarm)
Record (manual record, continuous record, motion detection or alarm triggered
record)
Alarm & Record
Event/Exception (event and exception information, appears at the lower-left corner
of the screen.)
Recording
Purpose:
Two kinds of record types are introduced in the following section, including Instant
Record and All-day Record. And for other record types, you may refer to the user manual
for detailed information.
After rebooting all the manual records enabled are canceled.
Instant Recording
On the live view window of each channel, there is a quick setting toolbar which shows
on the bottom of the window when you click on it.

HIKVISION DS-7108NI-E1/V/W Specifications

General

Maximum resolution	- pixels
Video input channels	8 channels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	12 W
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv6, UPnP, SNMP, NTP, SADP, DDNS, SMTP, NFS, iSCSI
HDD capacity	0 GB
HDD interface	-
Maximum storage capacity	- TB
Number of HDDs installed	0

Weight and Dimensions

Width	870 mm
Height	157 mm
Weight	530 g
