HIKVISION DS-7208HTHI-K2 User Manual

Network Video Recorder User Manual
115
Start playing the video of camera.
Click Smart.
From the toolbar at the bottom of the playing window, click the motion/line crossing/
intrusion icon for search.
Playback by Smart Search
Set the rules and areas for smart search of line crossing detection, intrusion detection
or motion detection event triggered recording.
 Line Crossing Detection
5) Click the icon.
6) Click on the image to specify the start point and end point of the line.
 Intrusion Detection
7) Click the icon.
8) Specify 4 points to set a quadrilateral region for intrusion detection. Only one region can
be set.
 Motion Detection
9) Click the icon.
10) Hold the mouse on the image to draw the detection area manually.
11) Click Search to search the matched video and start to play it.
Play Custom Searched Files
Purpose:
You can play the files by custom search with different conditions.

HIKVISION DS-7208HTHI-K2 Specifications

General

Voltage	12 V
Product color	Black
LED indicators	Yes
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio formats supported	G.711
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.265 Pro+, H.265 Pro, H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	8MP/5MP/4MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF
Audio input	4
BNC input ports	8
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Number of HDDs supported	2
Power consumption (max)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Optical drive included	No

Weight and Dimensions

Depth	320 mm
Width	380 mm
Height	48 mm
Weight	2000 g
