Network Video Recorder User Manual
144
Chapter 13 VCA Event Alarm
The device supports receiving the VCA detections sent by connected IP cameras. Enable and
configure the VCA detection on the IP camera settings interface first.
VCA detections must be supported by the connected IP camera.
Refer to the User Manual of Network Camera for the detailed instructions for the VCA
detection.
Human Body Detection
Purpose:
The human body detection is used to detect the human body appearing in the monitoring scene,
and capture the human body pictures.
This feature is available only when the connected camera supports the human body detection.
Go to System > Event > Smart Event.
Click Human Body.
Select the camera to configure the human body detection.
Check Save VCA Picture to save the captured pictures of human body detection.
Check Target of Interest (Human Body) to discard non-human body pictures and videos
which are not triggered by human body detection.
Set detection area.
1) Select the detection area to configure from the Area drop-down list. Up to 8 detection
areas are selectable.
2) Check the checkbox of Enable Area to enable the selected detection area.
3) Edit the area name in the Scene Name. The scene name can contain up to 32 characters.
To Next Page
